BLUEHELIX ALPHA

WALL HUNG CONDENSING BOILERS INSTANTANEOUS DHW PRODUCTION

> STRENGTHS:

- Boiler with single-circuit stainless steel primary exchanger without joints and/or welding, it maintains high efficiency even in old systems.

- MC²: Multi Combustion Control, new combustion system with gas-adaptive patented technology of industrial origin for better adaptability of use to the varying gas mains conditions (e.g. pressure fluctuations or drops)

- M.L.R: Methane, LPG, Propane-air Ready with a simple configuration the boiler can run on methane, LPG and propane-air without using additional conversion kits

- Instantaneous production of domestic hot water with a dedicated DHW plate exchanger

- User interface with display and multi-purpose keys to adjust and set the parameters

- Bypass as per standard

Technical Data

> ADVANTAGES OF BLUEHELIX ALPHA:

- Solar system set-up: set up for the production of domestic hot water combined with solar panel systems

- Flue ducting: particularly suitable for operation in flues requiring “heavy duty” pipes thanks to approval for operation with 50mm diameter flue outlets.

- Minimum polluting emissions (class 6 according to EN 15502-1)

- Sliding temperature operating mode through outdoor probe (optional)

- Low consumption modulating circulator (ErP Ready - Class A)

- A+ SYSTEM: (for mod. 28C and 34C) combined with the modulating remote control CONNECT, it reaches the top efficiency class A+ (scale from G to A+++)

- User interface with display and multi-purpose keys to adjust and set the parameters

- Digital flame control with three ignition attempts if operation gets blocked due to failed flame detection (methane mod.)

- Place of installation: also outdoors, in a partially protected place down to -5°C as per standard and even -15°C with the addition of the optional antifreeze heaters kit

- Removable casing into three pieces for easier maintenance or inspection.

- F.P.S.: Flue gas Protection System. The optional flue gas accessory (041106X0 - Exhaust gas check valve kit), which can be installed outside the boiler, allows an easy connection to pressurised collective flue systems (e.g. in restructuring), in accordance with the UNI 7129 standard.

NOTE: the kit cannot be used in recessed installations.
